Q-D Sheaves for "C" Belts								C
	Standard Keyseats
Table No.1
Bore Range		Keyseat
1/2" —  9/16"		1/8" x 1/16"
5/8 — 7/8		3/16 x 3/32
15/16 — 1 1/4		1/4 x 1/8
1 5/16 — 1 3/8		5/16 x 5/32
1 7/16 — 1 3/4		3/8 x 3/16
1 13/16 — 2 1/4		1/2 x 1/4
2 5/16 — 2 3/4		5/8 x 5/16
2 13/16 — 3 1/4		3/4 x 3/8
3 3/8 — 3 3/4		7/8 x 7/16
3 7/8 — 4 1/2		1 x 1/2
TYPE A		TYPE B		TYPE C		TYPE D		TYPE E
Table No.2		Specifications
Part No.	Bushing	Borre    Range	Type★	Datum"C"	O.D.	E	L	M	Wt.         Less    Bushing
1 GROOVE, F = 1 1/4"
1C70SF	SF	1/2" — 2 15/16"	D-1	7.0"	7.40"	27/32"	2 1/16"	1/32"	10
1C75SF	SF	1/2 — 2 15/16	D-2	7.5	7.90	27/32	2 1/16	1/32	12
1C80SF	SF	1/2 — 2 15/16	D-2	8.0	8.40	27/32	2 1/16	1/32	13
1C85SF	SF	1/2 — 2 15/16	D-2	8.5	8.90	27/32	2 1/16	1/32	14
1C90SF	SF	1/2 — 2 15/16	D-3	9.0	9.40	27/32	2 1/16	1/32	15
1C95SF	SF	1/2 — 2 15/16	D-3	9.5	9.90	27/32	2 1/16	1/32	16
1C100SF	SF	1/2 — 2 15/16	D-3	10.0	10.40	27/32	2 1/16	1/32	17
1C105SF	SF	1/2 — 2 15/16	D-3	10.5	10.90	27/32	2 1/16	1/32	18
1C110SF	SF	1/2 — 2 15/16	D-3	11.0	11.40	27/32	2 1/16	1/32	19
1C120SF	SF	1/2 — 2 15/16	D-3	12.0	12.40	27/32	2 1/16	1/32	20
1C130SF	SF	1/2 — 2 15/16	D-3	13.0	13.40	27/32	2 1/16	1/32	22
1C140SF	SF	1/2 — 2 15/16	D-3	14.0	14.40	27/32	2 1/16	1/32	24
1C160SF	SF	1/2 — 2 15/16	D-3	16.0	16.40	27/32	2 1/16	1/32	26
1C180SF	SF	1/2 — 2 15/16	D-3	18.0	18.40	27/32	2 1/16	1/32	30
1C200SF	SF	1/2 — 2 15/16	D-3	20.0	20.40	27/32	2 1/16	1/32	35
1C240SF	SF	1/2 — 2 15/16	D-3	24.0	24.40	27/32	2 1/16	1/32	41
2 GROOVES, F = 2 1/4"
2C70SF	SF	1/2 — 2 15/16	D-1	7.0	7.40	3/32	2 1/16	9/32	15
2C75SF	SF	1/2 — 2 15/16	D-1	7.5	7.90	3/32	2 1/16	9/32	17
2C80SF	SF	1/2 — 2 15/16	D-1	8.0	8.40	3/32	2 1/16	9/32	18
2C85SF	SF	1/2 — 2 15/16	D-2	8.5	8.90	3/32	2 1/16	9/32	19
2C90SF	SF	1/2 — 2 15/16	D-2	9.0	9.40	3/32	2 1/16	9/32	20
2C95SF	SF	1/2 — 2 15/16	D-2	9.5	9.90	3/32	2 1/16	9/32	21
2C100SF	SF	1/2 — 2 15/16	D-3	10.0	10.40	3/32	2 1/16	9/32	22
2C105SF	SF	1/2 — 2 15/16	D-3	10.5	10.90	3/32	2 1/16	9/32	23
2C110SF	SF	1/2 — 2 15/16	D-3	11.0	11.40	3/32	2 1/16	9/32	24
2C120SF	SF	1/2 — 2 15/16	D-3	12.0	12.40	11/32	2 1/16	17/32	25
2C130SF	SF	1/2 — 2 15/16	D-3	13.0	13.40	11/32	2 1/16	17/32	28
2C140SF	SF	1/2 — 2 15/16	D-3	14.0	14.40	11/32	2 1/16	17/32	31
2C160SF	SF	1/2 — 2 15/16	D-3	16.0	16.40	11/32	2 1/16	17/32	36
2C180SF	SF	1/2 — 2 15/16	D-3	18.0	18.40	11/32	2 1/16	17/32	39
2C200SF	SF	1/2 — 2 15/16	D-3	20.0	20.40	11/32	2 1/16	17/32	48
2C240SF	SF	1/2 — 2 15/16	D-3	24.0	24.40	11/32	2 1/16	17/32	60
2C300F	F	1 — 4	C-3	30.0	30.40	1 7/32	3 3/4	9/32	85
Table No.3
Part No.	Bushing	Borre    Range	Type★	Datum"C"	O.D.	E	L	M	Wt.         Less    Bushing
3 GROOVES, F = 3 1/4"
3C50SD	SD	1/2" — 2"	A-1	5.0"	5.40"	19/32"	1 13/16"	27/32"	10
3C55SD	SD	1/2 — 2	A-1	5.5	5.90	19/32	1 13/16	27/32	12
3C60SF	SF	1/2 — 2 15/16	D-1	6.0	6.40	23/32	2 1/16	1 29/32	15
3C70SF	SF	1/2 — 2 15/16	A-1	7.0	7.40	13/32	2 1/16	25/32	18
3C75SF	SF	1/2 — 2 15/16	A-1	7.5	7.90	13/32	2 1/16	25/32	20
3C80E	E	7/8 — 3 1/2	B-1	8.0	8.40	17/32	2 3/4	1/32	26
3C85E	E	7/8 — 3 1/2	B-1	8.5	8.90	17/32	2 3/4	1/32	29
3C90E	E	7/8 — 3 1/2	A-1	9.0	9.40	15/32	2 3/4	1/32	32
3C95E	E	7/8 — 3 1/2	A-2	9.5	9.90	15/32	2 3/4	1/32	34
3C100E	E	7/8 — 3 1/2	A-2	10.0	10.40	15/32	2 3/4	1/32	36
3C105E	E	7/8 — 3 1/2	A-3	10.5	10.90	15/32	2 3/4	1/32	38
3C110E	E	7/8 — 3 1/2	A-3	11.0	11.40	15/32	2 3/4	1/32	40
3C120E	E	7/8 — 3 1/2	A-3	12.0	12.40	15/32	2 3/4	1/32	43
3C130E	E	7/8 — 3 1/2	A-3	13.0	13.40	15/32	2 3/4	1/32	45
3C140E	E	7/8 — 3 1/2	A-3	14.0	14.40	15/32	2 3/4	1/32	51
3C160E	E	7/8 — 3 1/2	A-3	16.0	16.40	15/32	2 3/4	1/32	59
3C180E	E	7/8 — 3 1/2	A-3	18.0	18.40	15/32	2 3/4	1/32	65
3C200E	E	7/8 — 3 1/2	D-3	20.0	20.40	7/32	2 3/4	23/32	70
3C240E	E	7/8 — 3 1/2	D-3	24.0	24.40	7/32	2 3/4	23/32	80
3C270F	F	1 - 4	D-3	27.0	27.40	21/32	3 3/4	5/32	105
3C300F	F	1 - 4	D-3	30.0	30.40	21/32	3 3/4	5/32	120
3C360F	F	1 - 4	D-3	36.0	36.40	21/32	3 3/4	5/32	140
3C440F	F	1 - 4	D-3	44.0	44.40	21/32	3 3/4	5/32	170
3C500F	F	1 - 4	D-3	50.0	50.40	21/32	3 3/4	5/32	190
4 GROOVES, F = 4 1/4"
4C50D	SD	1/2 — 2	A-1	5.0	5.40	27/32	1 13/16	1 19/32	12
4C55SD	SD	1/2 — 2	A-1	5.5	5.90	27/32	1 13/16	1 19/32	14
4C60SF	SF	1/2 — 2 15/16	A-1	6.0	6.40	21/32	2 1/16	1 17/32	17
4C70SF	SF	1/2 — 2 15/16	A-1	7.0	7.40	21/32	2 1/16	1 17/32	21
4C75SF	SF	1/2 — 2 15/16	A-1	7.5	7.90	21/32	2 1/16	1 17/32	25
4C80E	E	7/8 — 3 1/2	A-1	8.0	8.40	25/32	2 3/4	23/32	30
4C85E	E	7/8 — 3 1/2	A-1	8.5	8.90	25/32	2 3/4	23/32	33
4C90E	E	7/8 — 3 1/2	A-1	9.0	9.40	25/32	2 3/4	23/32	35
4C95E	E	7/8 — 3 1/2	A-2	9.5	9.90	25/32	2 3/4	23/32	38
4C100E	E	7/8 — 3 1/2	A-2	10.0	10.40	25/32	2 3/4	23/32	40
4C105E	E	7/8 — 3 1/2	A-2	10.5	10.90	25/32	2 3/4	23/32	43
4C110E	E	7/8 — 3 1/2	A-2	11.0	11.40	25/32	2 3/4	23/32	46
4C120E	E	7/8 — 3 1/2	A-3	12.0	12.40	25/32	2 3/4	23/32	50
4C130E	E	7/8 — 3 1/2	A-3	13.0	13.40	25/32	2 3/4	23/32	54
4C140E	E	7/8 — 3 1/2	A-3	14.0	14.40	25/32	2 3/4	23/32	59
4C160E	E	7/8 — 3 1/2	A-3	16.0	16.40	25/32	2 3/4	23/32	65
4C180E	E	7/8 — 3 1/2	A-3	18.0	18.40	25/32	2 3/4	23/32	73
4C200E	E	7/8 — 3 1/2	A-3	20.0	20.40	9/32	2 3/4	1 7/32	82
4C240E	F	1 — 4	D-3	24.0	24.40	3/32	3 3/4	19/32	105
4C270E	F	1 — 4	D-3	27.0	27.40	3/32	3 3/4	19/32	125
4C300E	F	1 — 4	D-3	30.0	30.40	3/32	3 3/4	19/32	142
4C360E	F	1 — 4	D-3	36.0	36.40	3/32	3 3/4	19/32	172
4C440J	J	1 1/2 — 4 1/2	C-3	44.0	44.40	0	4 5/8	3/8	225
4C500J	J	1 1/2 — 4 1/2	C-3	50.0	50.40	0	4 5/8	3/8	260
5 GROOVES, F = 5 1/4"
5C60SF	SF	1/2 — 2 15/16	A-1	6.0	6.40	1 1/32	2 1/16	2 5/32	21
5C70SF	SF	1/2 — 2 15/16	A-1	7.0	7.40	1 1/32	2 1/16	2 5/32	26
5C75SF	SF	1/2 — 2 15/16	A-1	7.5	7.90	1 1/32	2 1/16	2 5/32	28
5C80E	E	7/8 — 3 1/2	A-1	8.0	8.40	1 5/32	2 3/4	1 11/32	33
5C85E	E	7/8 — 3 1/2	A-1	8.5	8.90	1 5/32	2 3/4	1 11/32	37
5C90E	E	7/8 — 3 1/2	A-1	9.0	9.40	1 5/32	2 3/4	1 11/32	40
5C95E	E	7/8 — 3 1/2	A-2	9.5	9.90	1 5/32	2 3/4	1 11/32	42
5C100E	E	7/8 — 3 1/2	A-2	10.0	10.40	1 5/32	2 3/4	1 11/32	45
5C105E	E	7/8 — 3 1/2	A-2	10.5	10.90	1 5/32	2 3/4	1 11/32	47
5C110E	E	7/8 — 3 1/2	A-2	11.0	11.40	1 5/32	2 3/4	1 11/32	50
5C120E	E	7/8 — 3 1/2	A-2	12.0	12.40	1 5/32	2 3/4	1 11/32	53
5C130E	E	7/8 — 3 1/2	A-3	13.0	13.40	1 5/32	2 3/4	1 11/32	58
5C140E	E	7/8 — 3 1/2	A-3	14.0	14.40	1 5/32	2 3/4	1 11/32	64
5C160E	E	7/8 — 3 1/2	A-3	16.0	16.40	1 5/32	2 3/4	1 11/32	73
5C180E	E	7/8 — 3 1/2	A-3	18.0	18.40	1 5/32	2 3/4	1 11/32	85
5C200F	F	1 — 4	D-3	20.0	20.40	3/32	3 3/4	1 19/32	98
5C240F	F	1 — 4	D-3	24.0	24.40	3/32	3 3/4	1 19/32	119
5C270F	F	1 — 4	D-3	27.0	27.40	3/32	3 3/4	1 19/32	153
5C300F	F	1 — 4	D-3	30.0	30.40	3/32	3 3/4	1 19/32	174
5C360J	J	1 1/2 — 4 1/2	A-3	36.0	36.40	1/16	4 5/8	9/16	206
5C440J	J	1 1/2 — 4 1/2	A-3	44.0	44.40	1/16	4 5/8	9/16	254
5C500J	J	1 1/2 — 4 1/2	A-3	50.0	50.40	1/16	4 5/8	9/16	274
Table No.4
Part No.	Bushing	Borre    Range	Type★	Datum"C"	O.D.	E	L	M	Wt.         Less    Bushing
6 GROOVES, F = 6 1/4"
6C60SF	SF	1/2" — 2 15/16"	A-1	6.0"	6.40"	1 1/32"	2 1/16"	3 5/32"	20
6C70SF	SF	1/2 — 2 15/16	A-1	7.0	7.40	1 1/32	2 1/16	3 5/32	26
6C75SF	SF	1/2 — 2 15/16	A-1	7.5	7.90	1 1/32	2 1/16	3 5/32	29
6C80E	E	7/8 — 3 1/2	A-1	8.0	8.40	1 5/32	2 3/4	2 11/32	36
6C85E	E	7/8 — 3 1/2	A-1	8.5	8.90	1 5/32	2 3/4	2 11/32	39
6C90E	F	1 — 4	A-1	9.0	9.40	1 1/32	3 3/4	1 15/32	51
6C95E	F	1 — 4	A-1	9.5	9.90	1 1/32	3 3/4	1 15/32	55
6C100F	F	1 — 4	A-1	10.0	10.40	1 1/32	3 3/4	1 15/32	59
6C105F	F	1 — 4	A-2	10.5	10.90	1 1/32	3 3/4	1 15/32	62
6C110F	F	1 — 4	A-2	11.0	11.40	1 1/32	3 3/4	1 15/32	66
6C120F	F	1 — 4	A-2	12.0	12.40	1 1/32	3 3/4	1 15/32	70
6C130F	F	1 — 4	A-3	13.0	13.40	1 1/32	3 3/4	1 15/32	74
6C140F	F	1 — 4	A-3	14.0	14.40	1 1/32	3 3/4	1 15/32	80
6C160F	F	1 — 4	A-3	16.0	16.40	1 1/32	3 3/4	1 15/32	89
6C180F	F	1 — 4	A-3	18.0	18.40	1 1/32	3 3/4	1 15/32	102
6C200F	F	1 — 4	A-3	20.0	20.40	17/32	3 3/4	1 31/32	112
6C240F	F	1 — 4	A-3	24.0	24.40	17/32	3 3/4	1 31/32	131
6C270J	J	1 1/2 — 4 1/2	A-3	27.0	27.40	1/16	4 5/8	1 9/16	160
6C300J	J	1 1/2 — 4 1/2	A-3	30.0	30.40	1/16	4 5/8	1 9/16	190
6C360J	J	1 1/2 — 4 1/2	A-3	36.0	36.40	1/16	4 5/8	1 9/16	232
6C440J	J	1 1/2 — 4 1/2	A-3	44.0	44.40	1/16	4 5/8	1 9/16	299
6C500M	M	2 — 5 1/2	B-3	50.0	50.40	7/32	6 3/4	23/32	320
8 GROOVES, F = 8 1/4"
8C80E	E	7/8 — 3 1/2	A-1	8.0	8.40	2 1/32	2 3/4	3 15/32	43
8C85E	E	7/8 — 3 1/2	A-1	8.5	8.90	2 1/32	2 3/4	3 15/32	48
8C90F	F	1 — 4	A-1	9.0	9.40	1 29/32	3 3/4	2 19/32	60
8C95F	F	1 — 4	A-1	9.5	9.90	1 29/32	3 3/4	2 19/32	65
8C100F	F	1 — 4	A-1	10.0	10.40	1 29/32	3 3/4	2 19/32	69
8C105F	F	1 — 4	A-2	10.5	10.90	1 29/32	3 3/4	2 19/32	73
8C110F	F	1 — 4	A-2	11.0	11.40	1 29/32	3 3/4	2 19/32	78
8C120F	F	1 — 4	A-3	12.0	12.40	1 29/32	3 3/4	2 19/32	83
8C130F	F	1 — 4	A-3	13.0	13.40	1 29/32	3 3/4	2 19/32	89
8C140F	F	1 — 4	A-3	14.0	14.40	1 29/32	3 3/4	2 19/32	97
8C160F	F	1 — 4	A-3	16.0	16.40	1 29/32	3 3/4	2 19/32	113
8C180F	F	1 — 4	A-3	18.0	18.40	1 29/32	3 3/4	2 19/32	131
8C200J	J	1 1/2 — 4 1/2	A-3	20.0	20.40	1/16	4 5/8	3 9/16	152
8C240J	J	1 1/2 — 4 1/2	A-3	24.0	24.40	1/16	4 5/8	3 9/16	185
8C270J	J	1 1/2 — 4 1/2	A-3	27.0	27.40	1/16	4 5/8	3 9/16	208
8C300J	J	1 1/2 — 4 1/2	A-3	30.0	30.40	1/16	4 5/8	3 9/16	230
8C360M	M	2 — 5 1/2	A-3	36.0	36.40	9/32	6 3/4	1 7/32	306
8C440M	M	2 — 5 1/2	A-3	44.0	44.40	9/32	6 3/4	1 7/32	440
8C500M	M	2 — 5 1/2	A-3	50.0	50.40	9/32	6 3/4	1 7/32	475
Table No.5
Part No.	Bushing	Bore    Range	Type★	Datum "C"	O.D.	E	L	M	Wt.         Less    Bushing
10 GROOVES, F = 10 1/4"
10C80E	E	7/8" — 3 1/2"	A-1	8.0"	8.40"	2 1/32"	2 3/4"	5 15/32"	65
10C85E	E	7/8 — 3 1/2	A-1	8.5	8.90	2 1/32	2 3/4	5 15/32	69
10C90J	J	1 1/2 — 4 1/2	A-1	9.0	9.40	2 1/16	4 5/8	3 9/16	73
10C95J	J	1 1/2 — 4 1/2	A-1	9.5	9.90	2 1/16	4 5/8	3 9/16	79
10C100J	J	1 1/2 — 4 1/2	A-1	10.0	10.40	2 1/16	4 5/8	3 9/16	84
10C105J	J	1 1/2 — 4 1/2	A-1	10.5	10.90	2 1/16	4 5/8	3 9/16	95
10C110J	J	1 1/2 — 4 1/2	A-1	11.0	11.40	2 1/16	4 5/8	3 9/16	104
10C120J	J	1 1/2 — 4 1/2	A-1	12.0	12.40	2 1/16	4 5/8	3 9/16	113
10C130J	J	1 1/2 — 4 1/2	A-3	13.0	13.40	2 1/16	4 5/8	3 9/16	121
10C140J	J	1 1/2 — 4 1/2	A-3	14.0	14.40	2 1/16	4 5/8	3 9/16	128
10C160J	J	1 1/2 — 4 1/2	A-3	16.0	16.40	2 1/16	4 5/8	3 9/16	146
10C180J	J	1 1/2 — 4 1/2	A-3	18.0	18.40	2 1/16	4 5/8	3 9/16	161
10C200J	J	1 1/2 — 4 1/2	A-3	20.0	20.40	2 1/16	4 5/8	3 9/16	175
10C240M	M	2 — 5 1/2	A-3	24.0	24.40	9/32	6 3/4	3 7/32	265
10C300M	M	2 — 5 1/2	A-3	30.0	30.40	9/32	6 3/4	3 7/32	310
10C360M	M	2 — 5 1/2	A-3	36.0	36.40	9/32	6 3/4	3 7/32	345
10C440M	M	2 — 5 1/2	A-3	44.0	44.40	9/32	6 3/4	3 7/32	450
10C500M	M	2 — 5 1/2	A-3	50.0	50.40	9/32	6 3/4	3 7/32	500
12 GROOVES, F = 12 1/4"
12C90J	J	1 1/2 — 4 1/2	A-1	9.0	9.40	2 9/16	4 5/8	5 1/16	80
12C95J	J	1 1/2 — 4 1/2	A-1	9.5	9.90	2 9/16	4 5/8	5 1/16	88
12C100J	J	1 1/2 — 4 1/2	A-1	10.0	10.40	2 9/16	4 5/8	5 1/16	95
12C105J	J	1 1/2 — 4 1/2	A-1	10.5	10.90	2 9/16	4 5/8	5 1/16	101
12C110J	J	1 1/2 — 4 1/2	A-1	11.0	11.40	2 9/16	4 5/8	5 1/16	111
12C120J	J	1 1/2 — 4 1/2	A-2	12.0	12.40	2 9/16	4 5/8	5 1/16	127
12C130J	J	1 1/2 — 4 1/2	A-3	13.0	13.40	2 9/16	4 5/8	5 1/16	137
12C140J	J	1 1/2 — 4 1/2	A-3	14.0	14.40	2 9/16	4 5/8	5 1/16	150
12C160J	J	1 1/2 — 4 1/2	A-3	16.0	16.40	2 9/16	4 5/8	5 1/16	170
12C180J	J	1 1/2 — 4 1/2	A-3	18.0	18.40	2 9/16	4 5/8	5 1/16	205
12C200M	M	2 — 5 1/2	A-3	20.0	20.40	9/32	6 3/4	5 7/32	245
12C240M	M	2 — 5 1/2	A-3	24.0	24.40	9/32	6 3/4	5 7/32	285
12C300M	M	2 — 5 1/2	A-3	30.0	30.40	9/32	6 3/4	5 7/32	355
12C360M	M	2 — 5 1/2	A-3	36.0	36.40	9/32	6 3/4	5 7/32	420
12C440M	M	2 — 5 1/2	A-3	44.0	44.40	9/32	6 3/4	5 7/32	515
12C500M	M	2 — 5 1/2	A-3	50.0	50.40	9/32	6 3/4	5 7/32	575
