Gripbelt Sheaves with Split Taper Bushings

5V

Bore Range

Standard Keyseats

Table No.1

Table No.2

Bushing No.

Bore Range

Bore Range

Keyseat

P1

1/2" — 1 3/4"

1/2 "— 9/16"

1/8" x 1/16"

Q1

3/4 — 2 11/16

5/8 — 7/8

3/16 x 3/32

Q2

1 — 2 5/8

15/16 — 1 1/4

1/4 x 1/8

R1

1 1/8 — 3 3/4

1 5/16 — 1 3/8

5/16 x 5/32

S1

1 11/16 — 4 1/4

1 7/16 — 1 3/4

3/8 x 3/16

U0

2 3/8 — 5 1/2

1 13/16 — 2 1/4

1/2 x 1/4

U1

2 3/8 — 5 1/2

2 5/16 — 2 3/4

5/8 x 5/16

2 13/16 — 3 1/4

3/4 x 3/8

3 3/8 — 3 3/4

7/8 x 7/16

3 7/8 — 4 1/4

1 x 1/2

4 9/16 — 5 1/2

1 1/4 x 5/8

1 3/8" Bore Bushing also available with 3/8×3/16"Keyway.

Table No.3

Specifications—Stock "3V" Sheaves

DIAMETERS

Part Number

TYPE

DIMENSIONS

Wt.      Less   Bush.

Pitch       "5V"       Belts

Out side

In side

Sheave

Bushing

O.L.

L

P

C

H

G

X

E

2 GROOVES, F =  1 11/16"

▲4.30"

4.40"

3 3/16"

2P5V44

P1

13-Solid

2 3/16"

1 15/16"

1/4"

—

3"

5/8"

1 5/16"

1/4"

3.8

▲4.50

4.60

2 7/8

2Q5V46

Q1

5

3 7/8

2 1/2

3/4

1 3/32"

4 1/8

—

1 3/4

9/32

6.6

▲4.80

4.90

3 1/8

2Q5V49

Q1

5

3 5/16

2 1/2

3/4

17/32

4 1/8

—

1 3/4

9/32

6.2

▲5.10

5.20

—

2Q5V52

Q1

16-Solid

2 25/32

2 1/2

3/4

1/16

4 1/8

3/4

1 3/4

9/32

5.6

▲5.40

5.50

—

2Q5V55

Q1

16-Solid

2 25/32

2 1/2

3/4

1/16

4 1/8

3/4

1 3/4

9/32

6.6

▲5.80

5.90

—

2Q5V59

Q1

16-Solid

2 25/32

2 1/2

3/4

1/16

4 1/8

3/4

1 3/4

9/32

7.6

▲6.20

6.30

—

2Q5V63

Q1

16-Solid

2 25/32

2 1/2

3/4

1/16

4 1/8

3/4

1 3/4

9/32

9.4

▲6.60

6.7

—

2Q5V67

Q1

16-Solid

2 25/32

2 1/2

3/4

1/16

4 1/8

3/4

1 3/4

9/32

11.0

7.00

7.10

—

2Q5V71

Q1

16-Solid

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

12.3

7.40

7.50

—

2Q5V75

Q1

16-Solid

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

14.1

7.90

8.00

6 1/4

2Q5V80

Q1

16-Web

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

11.6

8.40

8.50

6 3/4

2Q5V85

Q1

16-Web

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

12.9

8.90

9.00

7 1/4

2Q5V90

Q1

16-Web

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

16.3

9.15

9.25

7 3/8

2Q5V92

Q1

16-Arm

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

15.1

9.65

9.75

7 7/8

2Q5V97

Q1

16-Arm

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

16.1

10.20

10.30

8 7/16

2Q5V103

Q1

16-Arm

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

18.8

10.80

10.90

9

2Q5V109

Q1

16-Arm

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

19.3

11.70

11.80

10

2Q5V118

Q1

16-Arm

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

21.4

12.40

12.50

10 3/4

2Q5V125

Q1

16-Arm

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

23.8

13.10

13.20

11 7/16

2Q5V132

Q1

16-Arm

2 25/32

2 1/2

25/32

1/32

4 1/8

3/4

1 3/4

9/32

25.5

13.90

14.00

12 1/4

2R5V140

R1

16-Arm

3 25/32

2 7/8

1 1/32

5/32

5 3/8

7/8

2

9/32

27.6

14.90

15.00

13 1/4

2R5V150

R1

16-Arm

3 25/32

2 7/8

1 1/32

5/32

5 3/8

7/8

2

9/32

30.9

15.90

16.00

14 1/4

2R5V160

R1

16-Arm

3 25/32

2 7/8

1 1/32

5/32

5 3/8

7/8

2

9/32

33.3

21.10

21.20

19 3/8

2R5V212

R1

16-Arm

3 25/32

2 7/8

1 1/32

5/32

5 3/8

7/8

2

9/32

47.5

27.90

28.00

26 1/4

2R5V280

R1

16-Arm

3 25/32

2 7/8

1 1/32

5/32

5 3/8

7/8

2

9/32

71.0

3 GROOVES, F =2 3/8"

▲4.30"

4.40"

3 3/16

3P5V44

P1

13-Solid

2 23/32"

1 15/16"

3/32"

17/32"

3"

5/8"

1 5/16"

1/4"

3.1

▲4.50

4.60

2 7/8

3Q5V46

Q1

5

4 3/4

2 1/2

3/4

1 25/32

4 1/8

—

1 3/4

9/32

7.6

▲4.80

4.90

3 1/8

3Q5V49

Q1

5

3 13/32

2 1/2

3/4

5/8

4 1/8

—

1 3/4

9/32

7.3

▲5.10

5.20

3 1/2

3Q5V52

Q1

5

3 13/32

2 1/2

3/4

5/8

4 1/8

—

1 3/4

9/32

5.8

▲5.40

5.50

3 3/4

3Q5V55

Q1

5

3 13/32

2 1/2

3/4

5/8

4 1/8

3/4

1 3/4

9/32

7.5

▲5.80

5.90

4 3/16

3Q5V59

Q1

13-Solid

2 31/32

2 1/2

5/16

3/16

4 1/8

3/4

1 3/4

9/32

8.6

▲6.20

6.30

4 9/16

3Q5V63

Q1

13-Solid

2 31/32

2 1/2

5/16

3/16

4 1/8

3/4

1 3/4

9/32

10.3

▲6.60

6.70

5

3Q5V67

Q1

13-Solid

2 31/32

2 1/2

5/16

3/16

4 1/8

3/4

1 3/4

9/32

12.0

7.00

7.10

5 3/8

3Q5V71

Q1

13-Web

2 31/32

2 1/2

5/16

3/16

4 1/8

3/4

1 3/4

9/32

13.9

7.40

7.50

5 3/4

3Q5V75

Q1

13-Web

2 31/32

2 1/2

5/16

3/16

4 1/8

3/4

1 3/4

9/32

16.0

7.90

8.00

6 1/4

3R5V80

R1

13-Web

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

17.2

8.40

8.50

6 3/4

3R5V85

R1

13-Web

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

20.5

8.90

9.00

7 1/4

3R5V90

R1

13-Web

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

22.2

9.15

9.25

7 3/8

3R5V92

R1

13-Web

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

24.1

9.65

9.75

7 7/8

3R5V97

R1

13-Web

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

24.8

10.20

10.30

8 7/16

3R5V103

R1

13-Web

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

26.4

10.80

10.90

9

3R5V109

R1

13-Web

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

28.0

11.70

11.80

10

3R5V118

R1

13-Web

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

31.9

12.40

12.50

10 3/4

3R5V125

R1

13-Arm

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

35.1

13.10

13.20

11 7/16

3R5V132

R1

13-Arm

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

29.0

13.90

14.00

12 1/4

3R5V140

R1

13-Arm

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

32.3

14.90

15.00

13 1/4

3R5V150

R1

13-Arm

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

35.0

15.90

16.00

14 1/4

3R5V160

R1

13-Arm

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

38.7

21.10

21.20

19 3/8

3R5V212

R1

13-Arm

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

52.0

27.90

28.00

26 1/4

3R5V280

R1

13-Arm

3 11/32

2 7/8

11/16

3/16

5 3/8

7/8

2

9/32

80.0

37.40

37.50

35 3/4

3S5V375

S1

16-Arm

4 3/4

4 3/8

1 17/32

15/32

6 3/8

1 1/16

3 5/16

3/8

147

49.90

50.00

48 1/4

3U5V500

U0

16-Arm

5 13/32

4 15/16

1 7/8

11/16

8 3/8

1 3/16

3 3/4

15/32

216

4 GROOVES, F =  3 1/16"

▲4.30"

4.40"

3"

4P5V44

P1

13-Solid

3 3/16"

1 15/32"

1/8"

7/8"

3"

5/8"

1 5/16"

1/4"

3.2

▲4.50

4.60

2 7/8

4Q5V46

Q2

5

5 1/4

3 1/2

3/4

1 15/32

4 1/8

—

2 3/4

9/32

8.6

▲4.80

4.90

3 1/8

4Q5V49

Q1

5

4 3/32

2 1/2

3/4

1 5/16

4 1/8

—

1 3/4

9/32

8.5

▲5.10

5.20

3 1/2

4Q5V52

Q1

5

4 3/32

2 1/2

3/4

1 5/16

4 1/8

—

1 3/4

9/32

7.8

▲5.40

5.50

3 3/4

4Q5V55

Q1

5

4 3/32

2 1/2

3/4

1 5/16

4 1/8

3/4

1 3/4

9/32

8.3

▲5.80

5.90

4 3/16

4Q5V59

Q1

13-Solid

4 3/32

2 1/2

0

9/16

4 1/8

3/4

1 3/4

9/32

10.1

▲6.20

6.30

4 9/16

4Q5V63

Q1

13-Solid

4 3/32

2 1/2

0

9/16

4 1/8

3/4

1 3/4

9/32

11.8

▲6.60

6.7

5

4Q5V67

Q1

13-Solid

4 3/32

2 1/2

0

9/16

4 1/8

3/4

1 3/4

9/32

13.6

7.00

7.10

5 3/8

4Q5V71

Q1

13-Web

3 11/32

2 1/2

0

9/16

4 1/8

3/4

1 3/4

9/32

15.9

7.40

7.50

5 3/4

4Q5V75

Q1

13-Web

3 11/32

2 1/2

0

9/16

4 1/8

3/4

1 3/4

9/32

18.4

7.90

8.00

6 1/4

4R5V80

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

19.4

8.40

8.50

6 3/4

4R5V85

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

22.8

8.90

9.00

7 1/4

4R5V90

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

24.5

9.15

9.25

7 3/8

4R5V92

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

26.6

9.65

9.75

7 7/8

4R5V97

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

28.0

10.20

10.30

8 7/16

4R5V103

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

30.8

10.80

10.90

9

4R5V109

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

31.7

11.70

11.80

10

4R5V118

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

35.3

12.40

12.50

10 3/4

4R5V125

R1

13-Web

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

37.9

13.10

13.20

11 7/16

4R5V132

R1

13-Arm

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

33.3

13.90

14.00

12 1/4

4R5V140

R1

13-Arm

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

36.5

14.90

15.00

13 1/4

4R5V150

R1

13-Arm

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

40.9

15.90

16.00

14 1/4

4R5V160

R1

13-Arm

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

43.3

21.10

21.20

19 3/8

4R5V212

R1

13-Arm

3 11/16

2 7/8

11/32

17/32

5 3/8

7/8

2

9/32

59.0

27.90

28.00

26 1/4

4S5V280

S1

16-Arm

4 3/4

4 3/8

1 3/16

1/8

6 3/8

1 1/16

3 5/16

3/8

135

37.40

37.50

35 3/4

4S5V375

S1

16-Arm

4 3/4

4 3/8

1 3/16

1/8

6 3/8

1 1/16

3 5/16

3/8

157

49.90

50.00

48 1/4

4R5V500

U0

16-Arm

5 13/32

4 15/16

4 15/16

11/32

8 3/8

1 1/16

3 3/4

15/32

239

5 GROOVES, F =3 3/4"                                                                                                                     For optimum sheave selection, see B5V Stock Sheave Listing on Page A-14.

▲4.50

4.60

2 7/8"

5Q5V46

Q2

5

5 15/16"

3 1/2"

3/4"

2 5/16"

4 1/8"

—

2 3/4"

9/32

8.9

▲4.80

4.90

3 1/8

5Q5V49

Q2

5

5 3/8

3 1/2

3/4

1

4 1/8

—

2 3/4

9/32

9.2

▲5.10

5.20

3 1/2

5Q5V52

Q2

5

4 25/32

3 1/2

3/4

1

4 1/8

3/4"

2 3/4

9/32

9.0

▲5.40

5.50

3 3/4

5Q5V55

Q2

5

4 25/32

3 1/2

3/4

1

4 1/8

3/4

2 3/4

9/32

10.8

▲5.80

5.90

4 3/16

5Q5V59

Q2

13-Solid

4 3/32

3 1/2

—

1/4

4 1/8

3/4

2 3/4

9/32

13.2

▲6.20

6.30

4 9/16

5Q5V63

Q2

13-Solid

4 3/32

3 1/2

—

1/4

4 1/8

3/4

2 3/4

9/32

15.9

▲6.60

6.70

5

5Q5V67

Q2

13-Solid

4 3/32

3 1/2

—

1/4

4 1/8

3/4

2 3/4

9/32

18.6

7.00

7.10

5 3/8

5Q5V71

Q2

13-Web

4 1/32

3 1/2

0

1/4

4 1/8

3/4

2 3/4

9/32

22.0

7.40

7.50

5 3/4

5Q5V75

Q2

13-Web

4 1/32

3 1/2

0

1/4

4 1/8

3/4

2 3/4

9/32

25.0

7.90

8.00

6 1/4

5R5V80

R1

15-Web

4 1/32

2 7/8

0

1/4

5 3/8

7/8

2

9/32

21.7

8.40

8.50

6 3/4

5R5V85

R1

15-Web

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

25.1

8.90

9.00

7 1/4

5R5V90

R1

15-Web

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

25.4

9.15

9.25

7 3/8

5R5V92

R1

15-Web

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

28.4

9.65

9.75

7 7/8

5R5V97

R1

15-Web

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

31.8

10.20

10.30

8 7/16

5R5V103

R1

15-Web

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

32.5

10.80

10.90

9

5R5V109

R1

15-Web

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

35.1

11.70

11.80

10

5R5V118

R1

15-Web

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

38.8

12.40

12.50

10 3/4

5R5V125

R1

15-Web

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

41.8

13.10

13.20

11 7/16

5R5V132

R1

15-Arm

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

37.1

13.90

14.00

12 1/4

5R5V140

R1

15-Arm

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

41.6

14.90

15.00

13 1/4

5R5V150

R1

15-Arm

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

45.0

15.90

16.00

14 1/4

5R5V160

R1

15-Arm

4 1/32

2 7/8

0

7/8

5 3/8

7/8

2

9/32

48.0

21.10

21.20

19 3/8

5S5V212

S1

13-Arm

4 31/32

4 3/8

27/32

7/32

6 3/8

1 1/16

3 5/16

3/8

90.0

24.90

25.00

23 1/4

5S5V250

S1

13-Arm

4 31/32

4 3/8

27/32

7/32

6 3/8

1 1/16

3 5/16

3/8

105

27.90

28.00

26 1/4

5S5V280

S1

13-Arm

4 31/32

4 3/8

27/32

7/32

6 3/8

1 1/16

3 5/16

3/8

120

37.40

37.50

35 3/4

5U5V375

U0

13-Arm

5 13/32

4 15/16

1 3/16

0

8 3/8

1 3/16

3 3/4

15/32

185

49.90

50.00

48 1/4

5U5V500

U0

13-Arm

5 13/32

4 15/16

1 3/16

0

8 3/8

1 3/16

3 3/4

15/32

244

6 GROOVES, F = 4 7/16"

7.00"

7.10"

5 3/8"

6Q5V71

Q2

15-Web

4 7/16"

3 1/2"

1/2"

7/16"

4 1/8"

3/4"

2 3/4"

9/32"

23.6

7.40

7.50

5 3/4

6Q5V75

Q2

15-Web

4 7/16

3 1/2

1/2

7/16

4 1/8

3/4

2 3/4

9/32

27.3

7.90

8.00

6 1/4

6R5V80

R1

15-Web

4 7/16

2 7/8

11/32

1 7/32

5 3/8

7/8

2

9/32

23.3

8.40

8.50

6 3/4

6R5V85

R1

15-Web

4 7/16

2 7/8

11/32

1 7/32

5 3/8

7/8

2

9/32

27.3

8.90

9.00

7 1/4

6R5V90

R1

15-Web

4 7/16

2 7/8

11/32

1 7/32

5 3/8

7/8

2

9/32

28.8

9.15

9.25

7 3/8

6R5V92

R1

15-Web

4 7/16

2 7/8

11/32

1 7/32

5 3/8

7/8

2

9/32

31.1

9.65

9.75

7 7/8

6R5V97

R1

15-Web

4 7/16

2 7/8

11/32

1 7/32

5 3/8

7/8

2

9/32

34.5

10.20

10.30

8 7/16

6R5V103

R1

15-Web

4 7/16

2 7/8

11/32

1 7/32

5 3/8

7/8

2

9/32

36.8

10.80

10.90

9

6R5V109

R1

15-Web

4 7/16

2 7/8

11/32

1 7/32

5 3/8

7/8

2

9/32

39.6

11.70

11.80

10

6R5V118

R1

15-Web

4 7/16

2 7/8

11/32

1 7/32

5 3/8

7/8

2

9/32

42.5

12.40

12.50

10 3/4

6S5V125

S1

13-Arm

5 5/16

4 3/8

1/2

9/16

6 3/8

1 1/16

3 5/16

3/8

65.0

13.10

13.20

11 7/16

6S5V132

S1

13-Arm

5 5/16

4 3/8

1/2

9/16

6 3/8

1 1/16

3 5/16

3/8

71.0

13.90

14.00

12 1/4

6S5V140

S1

13-Arm

5 5/16

4 3/8

1/2

9/16

6 3/8

1 1/16

3 5/16

3/8

70.0

14.90

15.00

13 1/4

6S5V150

S1

13-Arm

5 5/16

4 3/8

1/2

9/16

6 3/8

1 1/16

3 5/16

3/8

69.0

15.90

16.00

14 1/4

6S5V160

S1

13-Arm

5 5/16

4 3/8

1/2

9/16

6 3/8

1 1/16

3 5/16

3/8

79.0

21.10

21.20

19 3/8

6S5V212

S1

13-Arm

5 5/16

4 3/8

1/2

9/16

6 3/8

1 1/16

3 5/16

3/8

97.0

24.90

25.00

23 1/4

6S5V250

S1

13-Arm

5 5/16

4 3/8

1/2

9/16

6 3/8

1 1/16

3 5/16

3/8

113

27.90

28.00

26 1/4

6S5V280

S1

13-Arm

5 5/16

4 3/8

1/2

9/16

6 3/8

1 1/16

3 5/16

3/8

128

37.40

37.50

35 3/4

6U5V375

U0

13-Arm

5 3/4

4 15/16

27/32

11/32

8 3/8

1 3/16

3 3/4

15/32

206

49.90

50.00

48 1/4

6U5V500

U0

13-Arm

5 3/4

4 15/16

27/32

11/32

8 3/8

1 3/16

3 3/4

15/32

271

8 GROOVES, F =5 13/16"

7.00"

7.10"

5 3/8"

8Q5V71

Q2

15-Web

5 13/16"

3 1/2"

1"

1 5/16"

4 1/8"

3/4"

2 3/4"

9/32"

27.9

7.40

7.50

5 3/4

8Q5V75

Q2

15-Web

5 13/16

3 1/2

1

1 5/16

4 1/8

3/4

2 3/4

9/32

32.1

7.90

8.00

6 1/4

8R5V80

R2

15-Web

6 1/16

4 7/8

1/32

29/32

5 3/8

7/8

4

9/32

45.3

8.40

8.50

6 3/4

8R5V85

R2

15-Web

6 1/16

4 7/8

1/32

29/32

5 3/8

7/8

4

9/32

45.5

8.90

9.00

7 1/4

8R5V90

R2

15-Web

6 1/16

4 7/8

1/32

29/32

5 3/8

7/8

4

9/32

50.1

9.15

9.25

7 3/8

8S5V92

S1

15-Web

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

47.3

9.65

9.75

7 7/8

8S5V97

S1

15-Web

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

50.0

10.20

10.30

8 7/16

8S5V103

S1

15-Web

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

63.0

10.80

10.90

9

8S5V109

S1

15-Web

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

71.0

11.70

11.80

10

8S5V118

S1

15-Web

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

85.0

12.40

12.50

10 3/4

8S5V125

S1

15-Arm

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

76.0

13.10

13.20

11 7/16

8S5V132

S1

15-Arm

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

79.0

13.90

14.00

12 1/4

8S5V140

S1

15-Arm

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

77.0

14.90

15.00

13 1/4

8S5V150

S1

15-Arm

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

83.0

15.90

16.00

14 1/4

8S5V160

S1

15-Arm

6

4 3/8

3/16

1 1/4

6 3/8

1 1/16

3 5/16

3/8

90.0

21.10

21.20

19 3/8

8U5V212

U1

13-Arm

7 11/16

7 1/8

1 13/32

3/32

8 3/8

1 1/2

5 5/8

15/32

175

24.90

25.00

23 1/4

8U5V250

U1

13-Arm

7 11/16

7 1/8

1 13/32

3/32

8 3/8

1 1/2

5 5/8

15/32

190

27.90

28.00

26 1/4

8U5V280

U1

13-Arm

7 11/16

7 1/8

1 13/32

3/32

8 3/8

1 1/2

5 5/8

15/32

222

37.40

37.50

35 3/4

8U5V375

U1

13-Arm

7 11/16

7 1/8

1 13/32

3/32

8 3/8

1 1/2

5 5/8

15/32

264

49.90

50.00

48 1/4

8U5V500

U1

13-Arm

7 11/16

7 1/8

1 13/32

3/32

8 3/8

1 1/2

5 5/8

15/32

393

10 GROOVES, F = 7 3/16"

7.90"

8.00"

6 1/4"

10R5V80

R2

15-Web

7 3/16"

4 7/8"

23/32"

1 19/32"

5 3/8"

7/8"

4"

9/32"

43.8

8.40

8.50

6 3/4

10R5V85

R2

15-Web

7 3/16

4 7/8

23/32

1 19/32

5 3/8

7/8

4

9/32

53.0

8.90

9.00

7 1/4

10R5V90

R2

15-Web

7 3/16

4 7/8

23/32

1 19/32

5 3/8

7/8

4

9/32

59.0

9.15

9.25

7 3/8

10S5V92

S1

15-Web

7 3/16

4 3/8

7/8

1 15/16

6 3/8

1 1/16

3 5/16

3/8

53.0

9.65

9.75

7 7/8

10S5V97

S1

15-Web

7 3/16

4 3/8

7/8

1 15/16

6 3/8

1 1/16

3 5/16

3/8

60.0

10.20

10.30

8 7/16

10S5V103

S1

15-Web

7 3/16

4 3/8

7/8

1 15/16

6 3/8

1 1/16

3 5/16

3/8

69.0

10.80

10.90

9

10S5V109

S1

15-Web

7 3/16

4 3/8

7/8

1 15/16

6 3/8

1 1/16

3 5/16

3/8

78.0

11.70

11.80

10

10S5V118

S1

15-Web

7 3/16

4 3/8

7/8

1 15/16

6 3/8

1 1/16

3 5/16

3/8

93.0

12.40

12.50

10 3/4

10U5V125

U1

13-Web

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

132

13.10

13.20

11 7/16

10U5V132

U1

13-Web

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

151

13.90

14.00

12 1/4

10U5V140

U1

13-Web

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

177

14.90

15.00

13 1/4

10U5V150

U1

13-Web

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

164

15.90

16.00

14 1/4

10U5V160

U1

13-Web

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

138

21.10

21.20

19 3/8

10U5V212

U1

13-Arm

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

188

24.90

25.00

23 1/4

10U5V250

U1

13-Arm

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

213

27.90

28.00

26 1/4

10U5V280

U1

13-Arm

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

238

37.40

37.50

35 3/4

10U5V375

U1

13-Arm

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

293

49.90

50.00

48 1/4

10U5V500

U1

13-Arm

8 3/8

7 1/8

23/32

25/32

8 3/8

1 1/2

5 5/8

15/32

428
